LG EP5G Overview

Designed for professional content creators and post-production editors, the 65EP5G 65″ 4K Smart OLED Professional Monitor from LG delivers the reference performance necessary for mission-critical productions. The eye-popping 65″ 4K OLED screen works in conjunction with LG’s proprietary software for optimized image fidelity. Calman software works to give accurate and uniform color representation, while SuperSign dials in proper white balance. The hardware is programmable with 1D & 3D LUTs, and multiple color-accurate profiles can be created and rapidly swapped to utilize different calibrations.

Key Features

4K UHD 3840 x 2160 OLED Panel
Calman for Accurate Color
SuperSign for Proper White Balance
Programmable Hardware with 1D & 3D LUTs
Supports Multiple Color Profiles
EYESAFE Certified
External Control Panel
webOS 5.0
2 x HDMI / 4 x SDI / 1 x USB
Ethernet Connectivity

Control Panel

A bottom-mounted control panel makes it easy to access frequently used functions and profiles, as well as the monitor’s settings and options. You can also choose on-screen features, such as Markers, Zoom, Audio Level Meters, and Waveform & Vector Scopes.

Eye Protection

With deadlines rarely being generous enough for a leisurely pace, long hours editing content becomes the norm. This is why LG constructed the 65EP5G to meet EYESAFE standards and protect your eyes from damaging blue light.

Additional Features

2 x HDMI and 4 x SDI in/out with BNC
SDI over IP via SFP+ case with an SFP module
Genlock input for use in broadcast and virtual production
webOS 5.0 built-in
Ethernet connectivity

LG EP5G Specs

Display

Panel Type	OLED
Display Size	65.00″ / 165.1 cm
Resolution	3840 x 1260
Aspect Ratio	16:9
Viewing Angle	178°
Touchscreen	No
Maximum Brightness	1000 cd/m²
Dynamic Contrast Ratio	1,850,000:1
Bit Depth / Color Support	10-Bit (1.07 Billion Colors)
HDR Compatibility	HDR10, Dolby Vision, Hybrid Log Gamma
Pixels Per Inch (ppi)	68 ppi
Color Gamut	98.5% DCI-P3
Image Controls	Blue Only, Marker Color, Picture-in-Picture, Pixel Zoom, Screen Markers, Vectorscope, Waveform

I/O

Video	2 x HDMI Type A Input 4 x BNC (12G-SDI/3G-SDI/6G-SDI/HD-SDI/SD-SDI) Input 4 x BNC (12G-SDI/3G-SDI/6G-SDI/HD-SDI/SD-SDI) Output
HDCP Support	Yes, Version 2.2
Embedded Audio	SDI: 16-Channel
Audio	1 x 1/8″ / 3.5 mm Headphone Output
Built-In Speaker	None
Other I/O	1 x RS-232 (1/8″ / 3.5 mm) Input 1 x USB 2.0 (USB Type-A) Input 1 x GPI/Serial (8P8C) Input 1 x Serial (8P8C) Output 1 x 10/100 Mb/s Ethernet (RJ45) Input/Output
Expansion Slots	1 x SFP+ Slot
Media/Memory Card Slot	None
Wi-Fi	None

Format Support

Gamma Curve

DCI-P3, HDR-HLG, ST2084, Standard

Power

AC Input Power	100 to 240 VAC, 50 / 60 Hz
Power Consumption	300 W (Typical) 470 W (Maximum)

Mounting

Mounting-Hole Pattern	300 x 300 mm
Mounting	None

Environmental

Certifications	CB, FCC-A, NRTL, as per Manufacturer
Operating Temperature	32 to 104°F / 0 to 40°C
Operating Humidity	10 to 80%

General

Dimensions	56.9 x 33.6 x 2.2″ / 1446.3 x 853.8 x 56.5 mm
Weight	68.3 lb / 31 kg, Excluding Stand 77.2 lb / 35 kg, Including Stand
