Screen Size (Diagonal) 55″

Resolution 1920 x 1080

Panel Type OLED

Bit Depth / Color Support 10-Bit (1.07 Billion Colors)

Color Gamut 120% Rec. 709

Brightness 400 cd/m

Viewing Angle (H x V) 178 x 178

Aspect Ratio 16:9

Dynamic Contrast Ratio 150,000:1, 150,000:1 Response Time 1 ms (GtG)

Response Time 1 ms (GtG)

Refresh Rate 120 Hz

Primary Connectivity Location Control Console

Input Ports 1 x HDMI Audio, Video (Rear) 1 x DisplayPort Audio, Video (Rear)

Output Ports 1 x DisplayPort Video (Rear) 1 x 1/8″ / 3.5 mm Audio (Rear)

USB Ports 2 x USB 2.0 Type-A (Rear)

Ethernet Ports Rear: 2

Control RS-232C via 1/8″ / 3.5 mm Input RS-232C via 1/8″ / 3.5 mm Output IR via 1/8″ / 3.5 mm Input

Digital Media Slot None

TV Tuner No

Display Orientation Landscape, Portrait

HDCP Support Yes

Hardness Rating 2H

Operating System webOS 4.0

RAM 16 GB

Power Consumption Maximum: 280.0 W Typical: 250.0 W Standby: 0.5 W

AC Input Power 100 to 240 VAC, 50 / 60 Hz

Operating Temperature 32 to 104 F / 0 to 40 C

Operating Humidity 10 to 80%

Certifications CE, CEC, FCC-A, as per Manufacturer

Glass Thickness 0.1″ / 3 mm

Bezel Thickness 7.9 mm (Right/Top/Left) 121.7 mm (Bottom)

Dimensions 48.2 x 31.9 x 0.2″ / 122.4 x 81.0 x 0.5 cm (Panel) 30.8 x 9.4 x 1.4″ / 78.2 x 23.9 x 3.6 cm (Signage Box)

Weight 25.6 lb / 11.6 kg 7.5 lb / 3.4 kg (Signage Box)

Package Weight 55 lb

Box Dimensions (LxWxH) 52.5 x 36 x 8″

Pro Idiom DRM

LG 55EW5G Overview Full HD (1920 x 1080) Native Resolution

LG 55EW5G Overview HDMI & DisplayPort Inputs

Ethernet Connectivity Connectivity via Included Console Digital Signage Capable

Ethernet Connectivity A New Level of See-Through View

Ethernet Connectivity LG transparent OLED digital signage lets viewers see spaces that previously would be hidden away behind a display, helping the display harmonize with its surroundings. Boasting vivid and clear colors with high transparency, this display provides visual enhancements to objects placed behind it, giving viewers an impressive wow factor. High Transparency, transparent OLED signage seamlessly and naturally blends into its surroundings thanks to its high transparency. These see-through digital displays turn static signage areas into open and interactive spaces. Accurate and Vivid Colors, transparent OLED signage is designed as a semi-assembled display, meaning you can install it in various ways to fit into existing structures and spaces with a variety of installation options via separately available hardware, complementing the venue in which it is installed. Additional Features Up to 30,000-hour typical lifetime

Ethernet Connectivity Featuring self-lighting pixels, the display maintains vivid colors and a high contrast ratio, even when the display becomes transparent. It brings content to life from wide viewing angles, and the content blends into its surroundings virtually seamlessly and naturally. Protective Tempered Glass

Ethernet Connectivity Touching a conventional display directly can cause damage or scratches, but the tempered front glass on this display protects against such external impacts. Expandable Design

18-hour/7-day operating time (with moving content only) Transparent bezel

Ethernet Connectivity Tempered, chemical-strengthened, shatter-proof protection glass with anti-reflective film

Ethernet Connectivity Temperature sensor Local content scheduling Group manager

Ethernet Connectivity USB plug & play Fail over RS-232C sync Local network sync

Ethernet Connectivity Video tag (4)

Ethernet Connectivity External input rotation Gapless playback Tile mode setting Setting data cloning SNMP ISM method Auto set ID Status mailing Control manager Crestron Inside PM mode Wake on LAN HDMI-CEC SI server setting

Ethernet Connectivity Pro Idiom DRM SuperSign CMS v3.0

Ethernet Connectivity SuperSign Control v1.7 / Control+ v1.9 SuperSign WB v3.7.15 SuperSign Media Editor v3.7 LG ConnectedCare LG 55EW5G Specs Display

Ethernet Connectivity Screen Size (Diagonal) 55″ Resolution 1920 x 1080 Panel Type OLED

Bit Depth / Color Support 10-Bit (1.07 Billion Colors)

Ethernet Connectivity Color Gamut 120% Rec. 709 Brightness 400 cd/m Viewing Angle (H x V) 178 x 178

Ethernet Connectivity Aspect Ratio 16:9

1 x HDMI Audio, Video (Rear)

1 x DisplayPort Audio, Video (Rear)

1 x DisplayPort Video (Rear) 1 x 1/8″ / 3.5 mm Audio (Rear)

2 x USB 2.0 Type-A (Rear)

Ethernet Ports Rear 2 Control

Ethernet Ports RS-232C via 1/8″ / 3.5 mm Input, via 1/8″ / 3.5 mm Output IR via 1/8″ / 3.5 mm Input Digital Media Slot None General TV Tuner No Display Orientation Landscape, Portrait HDCP Support Yes Surface Hardness Rating 2H Hardware

Ethernet Ports Operating System webOS 4.0 RAM 16 GB Electrical

Power Consumption Maximum 280.0 W

Power Consumption Typical 250.0 W

Power Consumption Standby 0.5 W

Power Consumption AC Input Power 100 to 240 VAC, 50 / 60 Hz Environmental

Power Consumption Operating Temperature 32 to 104 F / 0 to 40 C

Power Consumption Operating Humidity 10 to 80% Certifications

Power Consumption CE, CEC, FCC-A, as per Manufacturer Physical Glass Thickness 0.1″ / 3 mm Bezel Thickness 7.9 mm (Right/Top/Left) 121.7 mm (Bottom) Dimensions 48.2 x 31.9 x 0.2″ / 122.4 x 81.0 x 0.5 cm (Panel) 30.8 x 9.4 x 1.4″ / 78.2 x 23.9 x 3.6 cm (Signage Box) Weight 25.6 lb / 11.6 kg 7.5 lb / 3.4 kg (Signage Box) Packaging Info Package Weight 55 lb

Power Consumption Box Dimensions (LxWxH) 52.5 x 36 x 8″

Screen Size (Diagonal)	55″
Resolution	1920 x 1080
Panel Type	OLED
Bit Depth / Color Support	10-Bit (1.07 Billion Colors)
Color Gamut	120% Rec. 709
Brightness	400 cd/m²
Viewing Angle (H x V)	178 x 178°
Aspect Ratio	16:9
Dynamic Contrast Ratio	150,000:1
Response Time	1 ms (GtG)
Refresh Rate	120 Hz

Primary Connectivity Location	Control Console
Input Ports	1 x HDMI – Audio, Video (Rear) 1 x DisplayPort – Audio, Video (Rear)
Output Ports	1 x DisplayPort – Video (Rear) 1 x 1/8″ / 3.5 mm – Audio (Rear)
USB Ports	2 x USB 2.0 Type-A (Rear)
Ethernet Ports	Rear: 2
Control	RS-232C via 1/8″ / 3.5 mm Input RS-232C via 1/8″ / 3.5 mm Output IR via 1/8″ / 3.5 mm Input
Digital Media Slot	None

Operating Temperature	32 to 104°F / 0 to 40°C
Operating Humidity	10 to 80%
Certifications	CE, CEC, FCC-A, as per Manufacturer

TV Tuner	No
Display Orientation	Landscape, Portrait
HDCP Support	Yes

Power Consumption	Maximum: 280.0 W Typical: 250.0 W Standby: 0.5 W
AC Input Power	100 to 240 VAC, 50 / 60 Hz

Glass Thickness	0.1″ / 3 mm
Bezel Thickness	7.9 mm (Right/Top/Left) 121.7 mm (Bottom)
Dimensions	48.2 x 31.9 x 0.2″ / 122.4 x 81.0 x 0.5 cm (Panel) 30.8 x 9.4 x 1.4″ / 78.2 x 23.9 x 3.6 cm (Signage Box)
Weight	25.6 lb / 11.6 kg 7.5 lb / 3.4 kg (Signage Box)

Package Weight	55 lb
Box Dimensions (LxWxH)	52.5 x 36 x 8″

LG 55EW5G Overview

Key Features

A New Level of See-Through View

High Transparency

Accurate and Vivid Colors

Protective Tempered Glass

Expandable Design

Additional Features

LG 55EW5G Specs

Display

Connectivity

General

Surface

Hardware

Electrical

Environmental

Physical

Packaging Info
