The SW-610-48P-F is a 48 port PoE+ front facing single space rackmount Gigabit switch with 4 SFP+ 10Gb ports (aggregable up to 40Gbps) with a total PoE power budget of 740W. Each of the SFP+ ports can be used alone or aggregated together to allow 20 or 40Gbps throughput to another switch. This L2/L3 switch with 176Gbps switching capacity provides VLAN, QoS and other powerful management features. Up to 16 switches can be grouped in a single pane user-interface allowing easy and comprehensive administration. Variable speed fans for quiet operation. ProWatch Integrated for support of remote monitoring and management.

Key Features

• PoE Self-Healing with auto-recovery and power scheduling
• 48 PoE+ Gigabit Ports
• 740 Watt total PoE budget
• Front-facing ports for AV racks
• 4 SFP+ Ports
• Aggregable up to 40Gbps
• Rack Mountable
• Group Manager -Single pane user interface for easy administration of multiple 510 and 610 series switches
• Three Year Warranty

Specifications

Max. Power Consumption 899W @ 100VAC
PoE Power Budget 740W
Switching Capacity 176 Gbps
Connection Type Wired
Layer Support L2
L3
Number of Ports 48
PoE Self Healing Per Port Basis
Port Location Front
Power Cord US Cord
Power Type AC
ProWatch Type ProWatch Integrated
SPF Port Type 4 x 10 Gigabit
Switch Type Managed
PoE+
VLAN Compliance 802.1Q
Operating Temperature +32°F to +122°F (0°C to +50°C)
Dimensions (H x L x W) 1.75 in (44mm) x 17.4 in (442mm) x 14.75 in (375mm)
Weight 12.4lbs (5.62g)
Warranty Three Year Limited Warranty (Parts & Labor)
