Inputs/Outputs 8x RJ45 Gigabit Ethernet PoE+ (30 W, 802.3at) 1x RJ45 Gigabit Ethernet WAN 1x SFP Gigabit Ethernet WAN 1x RJ45 Gigabit Ethernet LAN 1x USB-C 1x USB-A
Stackable No
Switching Bandwidth 20 Gb/s
PoE Power Budget 110 W
Layer Services Supported Layer 2, Layer 3
Supported Protocols DHCP Server IGMP Snooping IPv4 IPv6 Link Aggregation Port Mirroring
Jumbo Frames Support 12,000 Bytes
MAC Address Table Size 16K
Security Features DHCP Snooping DoS Attack Prevention RADIUS Authentication Storm Control
Latency 2.2 s
Forwarding Rate 14.88 Mpps
Packet Buffer 16 Mb
CPU Single-Core: Up to 1.25 GHz Cortex A9
Memory 2 GB
PoE per Port 30 W
Power Draw 132.25 W (Max) 6.4 W (Standby)
Power Supply Type Internal
Operating Temperature 32 to 77 F / 0 to 45 C
Operating Humidity 90%
Storage Temperature -4 to 158 F / -20 to 70 C
Storage Humidity 95%
Noise Level 0.0 dB
Certifications No
Cooling System Passive
Mean Time Between Failures (MTBF) 0.5 Million Hours
Material of Construction Metal
Indicator Lights Yes
Rack Mountable Yes 1 RU
Dimensions 8.3 x 5.5 x 1.6″ / 210 x 140 x 40 mm
Weight 6.28 lb / 2.85 kg
Package Weight 5.09 lb
Box Dimensions (LxWxH) 11.4 x 8.7 x 3.8″
Netgear GSM4210PD-100NAS Overview Featuring a 20 Gb/s switching capacity, a 14.88 Mpps forwarding rate, and a simplified user interface with Netgear IGMP Plus providing multicast functionality, the AV Line M4250 is designed to minimize hassles so you can focus on making quality broadcasts. Easy Configuration
Netgear GSM4210PD-100NAS Overview A streamlined interface enables factory default AV settings or user-specified AV profiles to be assigned to individual ports with just a few clicks. Pre-Configured for Multicast
Netgear GSM4210PD-100NAS Overview Netgear IGMP Plus provides multicast functionality right out of the box for most AV over IP applications. There’s little to no setup required for clear Video over IP delivery. Quiet Design
Netgear GSM4210PD-100NAS Overview The fanless design provides silent operation, so you can broadcast without disruptions. Automatic Configuration
Netgear GSM4210PD-100NAS Overview Auto-trunk and auto-LAG functionality auto connects with other M4250 and M4300 switches. AVB Support
Netgear GSM4210PD-100NAS Overview Updating to the latest firmware enables the Audio Video Bridging (AVB) profile, allowing this switch to connect to compatible devices with improved synchronization, reliability, and performance.
8x RJ45 Gigabit Ethernet PoE+ (30 W, 802.3at)
1x RJ45 Gigabit Ethernet LAN 1x USB-C 1x USB-A Stackable No Switching Bandwidth 20 Gb/s
1x SFP Gigabit Ethernet WAN Single-Core Up to 1.25 GHz Cortex A9 Memory 2 GB Electrical PoE per Port 30 W
PoE Power Budget 110 W Power Draw 132.25 W (Max) 6.4 W (Standby)
Power Supply Type Internal Environmental Operating Temperature 32 to 77 F / 0 to 45 C
Power Supply Type Internal Environmental Operating Humidity 90% Storage Temperature -4 to 158 F / -20 to 70 C Storage Humidity 95%
Power Supply Type Internal Environmental Noise Level 0.0 dB General Certifications No Cooling System Passive
Power Supply Type Internal Environmental Mean Time Between Failures (MTBF) 0.5 Million Hours Material of Construction Metal Indicator Lights Yes Rack Mountable Yes 1 RU Dimensions 8.3 x 5.5 x 1.6″ / 210 x 140 x 40 mm Weight 6.28 lb / 2.85 kg Packaging Info Package Weight 5.09 lb
Power Supply Type Internal Environmental Box Dimensions (LxWxH) 11.4 x 8.7 x 3.8″
