Display System 1-Chip 0.80″ DLP
Native Resolution 1920 x 1200
Maximum Brightness 12,000 Lumens (ISO)
Throw Ratio 1.36 to 2.10:1 (200″ Screen Size @ 24.6′ / 7.5 m)
Projection Size 70 to 700″ / 1.8 to 17.8 m
HDR Support Yes, HDR10/Hybrid Log Gamma
Inputs/Outputs 2x HDMI Audio, Video Input 1x DisplayPort Audio, Video Input 1x USB-A Data, LAN Input 1x USB-A Power Output 1x RJ45 (Ethernet) Control, Data, LAN Input/Output 1x DE-9/DB-9 (RS-232) Control Input 1x DE-9/DB-9 (RS-232) Control Output 1x BNC Control Input 1x BNC Control Output 1x 1/8″ / 3.5 mm Mini Remote Input 1x 1/8″ / 3.5 mm Mini Remote Output 1x DE-9/DB-9 Remote Input
Light Source Laser Phosphor
On-Screen Resolution Up to 3840 x 2160 via Pixel-Shift Technology
Supported Resolutions Maximum: 3840 x 2400
Aspect Ratio Native: 16:10 Supported: 16:9
Dynamic Contrast Ratio 20,000:1, 20,000:1 Scan
Scan Horizontal: 27 to 291.6kHz Vertical: 24 to 240Hz
Includes Lens Yes
Focus Manual Powered
Aperture f/1.84 to 2.31
Focal Length 23.9 to 37.2mm
Lens Shift Vertical: 60% Horizontal: 29%
Optical Zoom Powered:
Throw Distance 6.73 to 108.33′ / 2.05 to 33.02 m
Keystone Correction Manual to Vertical: 40 Manual to Horizontal: 40
Multi-Input Support (PIP/PBP) Not Specified by Manufacturer
Ceiling Mountable Yes
Rear Screen Projection Yes
Built-In Speaker No
Projection Tilt Option Yes
HDCP Support Yes, Version 2.3
Media/Memory Card Slot No
Number of Expansion Slots 1
Mobile App Compatible Yes, Adapter Required (Not Included): Android & iOS
Wireless LAN / Wi-Fi No
Bluetooth No
Expected Lamp Life Medium Brightness: 20,000 Hours Low Brightness: 24,000 Hours
Fan Noise Medium Brightness: 39 dB
Security Cable Lock Slot Password Protection
Input Power 100 to 240 VAC, 50 / 60 Hz
Power Consumption Full Brightness:
Operating Conditions 32 to 113 F / 0 to 45 C at 10 to 80% Humidity
Dimensions (W x H x D) 19.6 x 8.3 x 25.5″ / 498.0 x 212.0 x 648.0 mm (with Lens and Feet) 19.6 x 7.7 x 21.2″ / 498.0 x 196.0 x 538.0 mm (without Lens and Feet)
Weight 63.5 lb / 28.8 kg
Panasonic REQ12 Overview Experience dynamic visuals and professional reliability with the PT-REQ12BU Laser DLP Projector in black from Panasonic . Featuring a brightness of 12,000 ISO lumens, standard-throw lens, 4K on-screen resolution, and 240 Hz projection capability, the PT-REQ12BU is ideal for demanding commercial applications, like museums and small to midsize entertainment venues.
Connect devices via HDMI and DisplayPort with support for 4K HDR and HDCP 2.3. It is LAN and RS-232 controllable and compatible with many popular 3rd party functions, such as Crestron Connected, AMX DD, and PJLink. It can be installed in any orientation to cover a wide-range of uses and tricky installations. Additionally the PT-REQ12BU is TAA compliant.
Panasonic REQ12 Overview UHD 4K via Panasonic’s Quad Pixel Drive
Panasonic REQ12 Overview The REQ12 Series features an hermetically sealed optical block with all-liquid cooling, enabling 20,000 hours of maintenance-free projection. To prevent interruptions, Backup Input switches to a secondary signal without screen-blanking if the primary is disrupted, while a Multi Laser Drive Engine prevents brightness loss in the unlikely event of diode failure.
Panasonic REQ12 Overview Effortless Workflow, Improved Expandability
NFC Projector Prep Using a mobile device and NFC technology, you can prepare your projector without it even being powered on. Tap the decal on the PT-REQ12BU to use the Smart Projector Control app to adjust settings that can then be applied when the projector is finally setup and powered on. This feature also lets you restore the PT-REQ12BU to factory defaults when powered off. Panasonic REQ12 Specs Display System 1-Chip 0.80″ DLP
NFC Projector Prep Native Resolution 1920 x 1200 Maximum Brightness 12,000 Lumens (ISO)
Throw Ratio Projection Size 70 to 700″ / 1.8 to 17.8 m, Size 70 to 700″ / 1.8 to 17.8 m Features Keystone Correction
Yes, HDR10/Hybrid Log Gamma Inputs/Outputs, Log Gamma
HDR Support 2x HDMI Audio, Video Input
1x DisplayPort Audio, Video Input
1x USB-A Data, LAN Input
1x RJ45 (Ethernet) Control, Data, LAN Input/Output 1x DE-9/DB-9 (RS-232) Control Input 1x DE-9/DB-9 (RS-232) Control Output 1x BNC Control Input 1x BNC Control Output 1x 1/8″ / 3.5 mm Mini Remote Input 1x 1/8″ / 3.5 mm Mini Remote Output 1x DE-9/DB-9 Remote Input Light Source Laser Phosphor Image Display Display System 1-Chip 0.80″ DLP, Control, Data, LAN Input/Output 1x DE-9/DB-9 (RS-232) Control Input 1x DE-9/DB-9 (RS-232) Control Output 1x BNC Control Input 1x BNC Control Output 1x 1/8″ / 3.5 mm Mini Remote Input 1x 1/8″ / 3.5 mm Mini Remote Output 1x DE-9/DB-9 Remote Input HDCP Support Yes, Version 2.3 Media/Memory Card Slot No Number of Expansion Slots 1 Hardware Mobile App Compatible
1x USB-A Power Output Native Resolution 1920 x 1200 On-Screen Resolution Up to 3840 x 2160 via Pixel-Shift Technology Supported Resolutions
1x USB-A Power Output Maximum 3840 x 2400 Maximum Brightness 12,000 Lumens (ISO)
Aspect Ratio Native 16:10
Aspect Ratio Supported 16:9
Aspect Ratio Horizontal 27 to 291.6kHz
Aspect Ratio Vertical 24 to 240Hz Lens Includes Lens Yes Focus Manual Powered Aperture f/1.84 to 2.31
Aspect Ratio Focal Length 23.9 to 37.2mm
Lens Shift Vertical 60%
Lens Shift Horizontal 29% Optical Zoom Powered: Throw Distance 6.73 to 108.33′ / 2.05 to 33.02 m
Manual to Vertical 40
Manual to Horizontal 40
HDR Support Multi-Input Support (PIP/PBP)
Input/Output Connectors Inputs/Outputs 2x HDMI Audio, Video Input
Yes, Adapter Required (Not Included) Android & iOS
1x USB-A Power Output Wireless LAN / Wi-Fi No Bluetooth No General Light Source Laser Phosphor Expected Lamp Life
1x USB-A Power Output Medium Brightness 20,000 Hours
1x USB-A Power Output Low Brightness 24,000 Hours
Fan Noise Medium Brightness 39 dB Security Cable Lock Slot Password Protection
Fan Noise Input Power 100 to 240 VAC, 50 / 60 Hz
Fan Noise Power Consumption Full Brightness: Operating Conditions 32 to 113 F / 0 to 45 C at 10 to 80% Humidity
Fan Noise Dimensions (W x H x D) 19.6 x 8.3 x 25.5″ / 498.0 x 212.0 x 648.0 mm (with Lens and Feet) 19.6 x 7.7 x 21.2″ / 498.0 x 196.0 x 538.0 mm (without Lens and Feet) Weight 63.5 lb / 28.8 kg
