Display System 3-Chip DLP
Native Resolution 1920 x 1200
Maximum Brightness 21,000 Lumens
HDR Support No
Inputs/Outputs 2x HDMI Audio, Video Input 1x DisplayPort Audio, Video Input 2x BNC Data Input/Output 1x DE-9/DB-9 Control Input 1x DE-9/DB-9 Control Output 1x 1/8″ / 3.5 mm Mini Remote Input 1x 1/8″ / 3.5 mm Mini Remote Output 1x DE-9/DB-9 Remote Input 1x RJ45 (Ethernet) LAN Input/Output 1x USB-A Data Input/Output 1x USB-A Power Output
Light Source Laser Phosphor
On-Screen Resolution Up to 3840 x 2160 via Four-Phase Pixel-Shift Technology
Aspect Ratio 16:10
Contrast Ratio 25,000:1
Includes Lens Yes
Keystone Correction Vertical: 45 Horizontal: 40
Multi-Input Support (PIP/PBP) Not Specified by Manufacturer
Ceiling Mountable Yes
HDCP Support Yes, Version 2.3
Number of Expansion Slots 1
Mobile App Compatible Yes: Android & iOS
Bluetooth No
Expected Lamp Life Full Brightness: 20,000 Hours Low Brightness: 24,000 Hours
Fan Noise Full Brightness: 46 dB Low Brightness: 43 dB
Input Power 100 to 240 VAC, 50 / 60 Hz
Power Consumption Full Brightness: 1540 W Standby Mode (Lamp Off): 1110 W
Operating Conditions 32 to 77 F / 0 to 45 C at 10 to 80% Humidity
Dimensions (W x H x D) 1.8 x 0.7 x 1.9′ / 550.0 x 220.0 x 570.0 mm
Weight 77.2 lb / 35 kg
Package Weight 96.5 lb
Box Dimensions (LxWxH) 30.75 x 30.25 x 17.5″
Even with such a high resolution, brightness, and DLP color, the PT-RQ25K’s image quality can be adjusted to suit your specific needs. Dynamic Contrast produces bright whites and deeper blacks, Gradation Smoother helps to reduce color-banding via the included remote, and point-based black-level adjustment supports edge-blending over curved surfaces for precise projections. Additional Features
Panasonic RQ25K Overview Multi-Laser Drive Engine helps prevent a loss of brightness if a diode fails
Panasonic RQ25K Overview Backup Input switches to a backup signal if the primary is interrupted
Panasonic RQ25K Overview Intel SDM-ready slot integrates preferred terminals with optional function boards
Panasonic RQ25K Overview Supports the Smart Projector Control app with NFC functionality
One DisplayPort and two HDMI inputs Panasonic RQ25K Specs Display System 3-Chip DLP
Compatible with Remote Preview Lite Native Resolution 1920 x 1200 Maximum Brightness 21,000 Lumens
HDR Support No Inputs/Outputs 2x HDMI Audio, Video Input
1x DisplayPort Audio, Video Input 2x BNC Data Input/Output 1x DE-9/DB-9 Control Input 1x DE-9/DB-9 Control Output 1x 1/8″ / 3.5 mm Mini Remote Input 1x 1/8″ / 3.5 mm Mini Remote Output 1x DE-9/DB-9 Remote Input
1x RJ45 (Ethernet) LAN Input/Output
1x USB-A Power Output Light Source Laser Phosphor Image Display Display System 3-Chip DLP, Power Output HDCP Support Yes, Version 2.3 Number of Expansion Slots 1 Hardware Mobile App Compatible
1x USB-A Data Input/Output Native Resolution 1920 x 1200 On-Screen Resolution Up to 3840 x 2160 via Four-Phase Pixel-Shift Technology Maximum Brightness 21,000 Lumens
1x USB-A Data Input/Output Aspect Ratio 16:10
1x USB-A Data Input/Output Contrast Ratio 25,000:1 Lens Includes Lens Yes Features Keystone Correction
1x USB-A Data Input/Output Vertical 45
1x USB-A Data Input/Output Horizontal 40
HDR Support No Multi-Input Support (PIP/PBP)
Input/Output Connectors Inputs/Outputs 2x HDMI Audio, Video Input
1x USB-A Data Input/Output Yes Android & iOS Bluetooth No General Light Source Laser Phosphor Expected Lamp Life
1x USB-A Data Input/Output Full Brightness 20,000 Hours
1x USB-A Data Input/Output Low Brightness 24,000 Hours
Fan Noise Full Brightness 46 dB
Fan Noise Low Brightness 43 dB
Fan Noise Input Power 100 to 240 VAC, 50 / 60 Hz
Power Consumption Full Brightness 1540 W
Standby Mode (Lamp Off) 1110 W
Power Consumption Operating Conditions 32 to 77 F / 0 to 45 C at 10 to 80% Humidity
Power Consumption Dimensions (W x H x D) 1.8 x 0.7 x 1.9′ / 550.0 x 220.0 x 570.0 mm Weight 77.2 lb / 35 kg Packaging Info Package Weight 96.5 lb
Power Consumption Box Dimensions (LxWxH) 30.75 x 30.25 x 17.5″
