Name: Panasonic PT-VMZ40U WUXGA 1080p 3LCD Projector
SKU: PT-VMZ40U
Price: $1,799.99 USD
Availability: InStock

Display System 3-Chip 0.64″ LCD

Native Chip Resolution 1920 x 1200 (WUXGA)

Supported Resolutions Maximum: 4K UHD – 3840 x 2160 @ 30 Hz

Maximum Brightness 4500 Lumens

Uniformity 85%

Aspect Ratio Native: 16:10

Dynamic Contrast Ratio 3,000,000:1, 3,000,000:1 Lens Focus Manual Lens

Focus Manual

Lens f/1.6 – 2.12 (f = 15.3 – 24.64 mm)

Lens Shift Vertical: 0 to 44% Horizontal: 20%

Optical Zoom Manual: 1.6x

Throw Distance 2.231 – 37.664′ / 0.68 – 11.48 m

Throw Ratio 1.09 to 1.77:1

Projection Size 30 – 300″ / 76.20 – 762.00 cm

Keystone Correction Vertical: 25 Horizontal: 35

Multi-Input Support (PIP/PBP) Not Specified by Manufacturer

Ceiling Mountable Yes

Rear Screen Projection Yes

Built-In Speaker Yes (Mono)

Speaker Power 10W

Projection Tilt Option Yes

Remote Yes

Inputs/Outputs 2 x HDMI (HDMI Type-A) Audio, Video Input 1 x VGA (DE-15/DB-15) Video Input 1 x VGA (DE-15/DB-15) Video Input/Output 1 x Composite (RCA) Video Input 1 x 2RCA Audio Input 2 x 1/8″ / 3.5 mm Mini Audio Input 1 x 1/8″ / 3.5 mm Mini Audio Output 1 x RS-232 (DE-9/DB-9) Control Input 1 x Ethernet (RJ45) LAN 1 x USB 2.0 (USB Type-A) Data Input

Wireless LAN / Wi-Fi No, Optional Adapter Available

Light Source Laser Phosphor

Expected Lamp Life Full Brightness: 20,000 Hours

Fan Noise Full Brightness: 37 dB Low Brightness: 27 dB

Security Cable Lock Slot Password Protection

Supported Photo File Types BMP, GIF, JPEG, JPG, PNG, TIFF

Supported Languages Arabic Czech Danish Dutch English Finnish French German Hungarian Italian Japanese Kazakh Korean Norwegian Polish Portuguese Romanian Russian Simplified Chinese Spanish Swedish Thai Turkish Vietnamese

AC Input Power 100 to 240 VAC, 50 / 60 Hz

Power Consumption Medium Brightness: 370 W Standby Mode (Lamp Off):

Operating Altitude 8858′ / 2700 m

Operating Temperature 32 to 113 F / 0 to 45 C

Operating Humidity 20 to 80%

Dimensions (W x H x D) 15.7 x 5.3 x 13.7″ / 39.9 x 13.5 x 34.8 cm With Feet at Shortest Position 15.7 x 4.5 x 13.7″ / 39.9 x 11.4 x 34.8 cm Excluding Protruding Parts

Weight 15.87 lb / 7.2 kg

Package Weight 22 lb

Box Dimensions (LxWxH) 22.25 x 17.5 x 10.25″

The PT-VMZ40U features composite video, VGA, and two HDMI inputs to connect to nearly any device. One VGA port can act either as a second input or an output to daisy-chain multiple projectors or displays. The projector is controllable via the included wireless remote control, Ethernet, or RS-232 with various control software options. Key Features

Brightness of 4500 Lumens WUXGA (1920 x 1200) Native Resolution

Brightness of 4500 Lumens Composite, VGA, 2x HDMI Inputs

VGA Output for Loop-Through Analog Audio Input and Output Integrated 10-Watt Speaker

VGA Output for Loop-Through Ethernet and RS-232 Controllable IR Remote Control Included

The PT-VMZ40U outputs up to 4500 lumens of brightness from a 15.9 lb body, bringing dynamic images where you need them. Enhanced Efficiency

VGA Output for Loop-Through The SOLID SHINE laser light source is designed to deliver up to 20,000 hours of consistent brightness and color accuracy.

The projector’s 1.6x zoom, horizontal and vertical lens shift, and 1.09 to 1.77:1 throw ratio help it fit in a variety of installation settings. Enhanced Connectivity

The PT-VMZ40U supports 4K UHD signals via HDMI, scaling resolutions down to Full HD 1920 x 1080 resolution. Reusable Filter

Flexible Installation Features The included filter can be washed and reused twice, providing a reduced total cost of ownership.

Flexible Installation Features Optional Wireless Adapter With a separately sold adapter, you can project wirelessly from your compatible source device. Panasonic VMZ40U Specs Image Display Display System 3-Chip 0.64″ LCD

Flexible Installation Features Native Chip Resolution 1920 x 1200 (WUXGA) Supported Resolutions

Flexible Installation Features Maximum 4K UHD – 3840 x 2160 @ 30 Hz Maximum Brightness 4500 Lumens Uniformity 85%

Aspect Ratio Native 16:10

Lens Shift Vertical 0 to 44%

Lens Shift Horizontal 20% Optical Zoom

Lens Shift Manual 1.6x

Throw Distance Throw Ratio 1.09 to 1.77:1

Projection Size 30 300″ / 76.20 – 762.00 cm Features Keystone Correction

Projection Size Vertical 25

Projection Size Horizontal 35

Projection Size Multi-Input Support (PIP/PBP)

Projection Size Not Specified by Manufacturer Ceiling Mountable Yes Rear Screen Projection Yes Built-In Speaker Yes (Mono) Speaker Power 10W

Projection Size Projection Tilt Option Yes Remote Yes

2 x HDMI (HDMI Type-A) Audio, Video Input

Input/Output Connectors Inputs/Outputs 1 x VGA (DE-15/DB-15) Video Input, x VGA (DE-15/DB-15) Video Input/Output, x Composite (RCA) Video Input

1 x 2RCA Audio Input 2 x 1/8″ / 3.5 mm Mini Audio Input 1 x 1/8″ / 3.5 mm Mini Audio Output 1 x RS-232 (DE-9/DB-9) Control Input

1 x Ethernet (RJ45) LAN

1 x USB 2.0 (USB Type-A) Data Input Hardware

Input/Output Connectors Inputs/Outputs Wireless LAN / Wi-Fi No, Optional Adapter Available General Light Source Laser Phosphor Expected Lamp Life

Input/Output Connectors Inputs/Outputs Full Brightness 20,000 Hours

Fan Noise Full Brightness 37 dB

Fan Noise Low Brightness 27 dB Security Cable Lock Slot Password Protection Supported Photo File Types

Fan Noise BMP, GIF, JPEG, JPG, PNG, TIFF Supported Languages Arabic Czech Danish Dutch English Finnish French German Hungarian Italian Japanese Kazakh Korean Norwegian Polish Portuguese Romanian Russian Simplified Chinese Spanish Swedish Thai Turkish Vietnamese

Fan Noise AC Input Power 100 to 240 VAC, 50 / 60 Hz

Power Consumption Medium Brightness 370 W Standby Mode (Lamp Off): Operating Altitude 8858′ / 2700 m

Power Consumption Operating Temperature 32 to 113 F / 0 to 45 C

Power Consumption Operating Humidity 20 to 80%

Power Consumption Dimensions (W x H x D) 15.7 x 5.3 x 13.7″ / 39.9 x 13.5 x 34.8 cm With Feet at Shortest Position 15.7 x 4.5 x 13.7″ / 39.9 x 11.4 x 34.8 cm Excluding Protruding Parts Weight 15.87 lb / 7.2 kg Packaging Info Package Weight 22 lb

Power Consumption Box Dimensions (LxWxH) 22.25 x 17.5 x 10.25″

Focus	Manual
Lens	f/1.6 – 2.12 (f = 15.3 – 24.64 mm)
Lens Shift	Vertical: 0 to 44% Horizontal: ± 20%
Optical Zoom	Manual: 1.6x
Throw Distance	2.231 – 37.664′ / 0.68 – 11.48 m
Throw Ratio	1.09 to 1.77:1
Projection Size	30 – 300″ / 76.20 – 762.00 cm

Keystone Correction	Vertical: ± 25° Horizontal: ± 35°
Multi-Input Support (PIP/PBP)	Not Specified by Manufacturer
Ceiling Mountable	Yes
Rear Screen Projection	Yes
Built-In Speaker	Yes (Mono)
Speaker Power	10W
Projection Tilt Option	Yes
Remote	Yes

Light Source	Laser Phosphor
Expected Lamp Life	Full Brightness: 20,000 Hours
Fan Noise	Full Brightness: 37 dB Low Brightness: 27 dB
Security	Cable Lock Slot Password Protection
Supported Photo File Types	BMP, GIF, JPEG, JPG, PNG, TIFF
Supported Languages	Arabic Czech Danish Dutch English Finnish French German Hungarian Italian Japanese Kazakh Korean Norwegian Polish Portuguese Romanian Russian Simplified Chinese Spanish Swedish Thai Turkish Vietnamese
AC Input Power	100 to 240 VAC, 50 / 60 Hz
Power Consumption	Medium Brightness: 370 W Standby Mode (Lamp Off): < 71 W
Operating Altitude	8858′ / 2700 m
Operating Temperature	32 to 113°F / 0 to 45°C
Operating Humidity	20 to 80%
Dimensions (W x H x D)	15.7 x 5.3 x 13.7″ / 39.9 x 13.5 x 34.8 cm With Feet at Shortest Position 15.7 x 4.5 x 13.7″ / 39.9 x 11.4 x 34.8 cm Excluding Protruding Parts
Weight	15.87 lb / 7.2 kg

Display System	3-Chip 0.64″ LCD
Native Chip Resolution	1920 x 1200 (WUXGA)
Supported Resolutions	Maximum: 4K UHD – 3840 x 2160 @ 30 Hz
Maximum Brightness	4500 Lumens
Uniformity	85%
Aspect Ratio	Native: 16:10
Dynamic Contrast Ratio	3,000,000:1

Package Weight	22 lb
Box Dimensions (LxWxH)	22.25 x 17.5 x 10.25″
