Screen Size (Diagonal) 43″
Resolution 3840 x 2160
Panel Type LCD
Brightness 350 cd/m
Viewing Angle (H x V) 178 x 178
Aspect Ratio 16:9
Contrast Ratio 4000:1
Response Time 8 ms
Backlighting Technology Edge LED
Primary Connectivity Location Display
Input Ports 2 x HDMI 2.0 Audio, Video 1 x DVI-D Video 1 x 1/8″ / 3.5 mm Audio
Output Ports 1 x 1/8″ / 3.5 mm Audio
USB Ports 2 x USB 2.0 Type-A
Ethernet Ports 1
Control RS-232C via 1/8″ / 3.5 mm Input/Output
Wi-Fi Built-in
Bluetooth Yes
TV Tuner No
Display Orientation Landscape, Portrait
HDCP Support Yes, Version 2.2
Surface Treatment Anti-Glare
Built-In Speakers Yes, 2 x 10 W
Speaker Configuration 2-Channel
Operating System Tizen 4.0
CPU 1.7 GHz Cortex A72 Quad-Core
Storage 8 GB
RAM 2.5 GB LPDDR4 1500 MHz
Supported Video File Types H.264/AVC, MPEG2, MPEG4, VC-1, VP8, VP9
Supported Audio File Types AC3
Supported Photo File Types JPEG, PNG
Power Consumption Standby: 0.5 W
AC Input Power 100 to 240 VAC, 50 / 60 Hz
Operating Temperature 32 to 104 F / 0 to 40 C
Operating Humidity 10 to 80%
Certifications ENERGY STAR, as per Manufacturer
Wall Mounting 200 x 200 mm
IP Rating IP5X
IR Sensor Yes
Bezel Thickness 9.2 mm (Right/Top/Left)
Duty Cycle 16 Hours / 7 Days
Dimensions 38.1 x 22.0 x 1.9″ / 967.5 x 557.7 x 48.3 mm
Weight 10 lb / 4.5 kg
Package Weight 28.5 lb
Box Dimensions (LxWxH) 42.75 x 26.75 x 6″
4000 1 Contrast Ratio
4000:1 Contrast Ratio
Built-In Wi-Fi & Bluetooth Connectivity
DVI-D & 2x HDMI 2.0 Inputs
USB Multimedia Playback SSSP with Tizen 4.0 OS Dual Built-In 10W Speakers Suitable for 16/7 Use Digital Signage Capable
Incredible 4K UHD Picture Quality Empower your customers to experience pure visual innovation with lifelike images in sharper picture quality than ever before. Intelligent UHD Upscaling
The QBR-B’s UHD upscaling feature is made possible by Samsung’s Crystal Processor 4K. This innovative technology allows the display to play lower resolution content at UHD-level quality while also improving the visibility of on-screen text and images.
Marvel at the Lifelike Color Expression
Incredible 4K UHD Picture Quality Immerse your customers in every picture with a wider range of color. Dynamic Crystal Display creates lifelike images allowing the viewer to see even the subtlest details. Cisco Webex Certified
The QBR-B series has achieved the most stringent of all testing by the Webex Device Business Unit and is fully certified. Cisco WebEx, together with the QBR-B series, provides the ultimate conferencing solution. Slim and Symmetrical Design
Incredible 4K UHD Picture Quality Samsung Workspace Secured by Knox With security provided by Knox, the display features Samsung Workspace, which supports wireless cloud service access and control of a computer without needing a physical connection. Samsung Workspace simplifies meeting spaces while also improving security. Wi-Fi Built-In
Incredible 4K UHD Picture Quality Built-in Wi-Fi allows for more personalized and interactive services as well as simplifying how businesses showcase content. Whether it’s to make networking simpler or enabling interactive beacon technology in-store, QBR-B series displays help businesses move into the future of retail.
Incredible 4K UHD Picture Quality Reliable, 16/7 Continuous Operation
Incredible 4K UHD Picture Quality Commercial-level cooling technologies offer dependable reliability with a 16/7 continuous runtime. Industry Standard Certified
The QBR-B is electromagnetic compatibility (EMC) class B compliant, meeting strict safety and reliability standards for operation. The displays are also registered by EPEAT, the global ecolabel for IT.
Incredible 4K UHD Picture Quality Powerful, All-in-One Solution
Incredible 4K UHD Picture Quality SSSP is an all-in-one solution that simplifies installation and maintenance. The embedded MagicINFO player S6, backed by the Tizen 4.0 operating system, allows for easy content management and playback without the need for a computer. Businesses can enjoy easy development, reinforced capability with multiple web formats and standards, and secured protection. Additional Features
Incredible 4K UHD Picture Quality MEGA dynamic contrast ratio
Incredible 4K UHD Picture Quality Temperature sensor Pivot Display
Incredible 4K UHD Picture Quality Clock battery (168 hours clock keeping)
Incredible 4K UHD Picture Quality Auto Source Switching & Recovery software LFD Home UI Button lock Hot key option
Incredible 4K UHD Picture Quality Plug & play (initial setting) ENERGY STAR 8.0 Samsung QB43R Specs Display
Incredible 4K UHD Picture Quality Screen Size (Diagonal) 43″ Resolution 3840 x 2160 Panel Type LCD Brightness 350 cd/m Viewing Angle (H x V) 178 x 178
Incredible 4K UHD Picture Quality Aspect Ratio 16:9
Incredible 4K UHD Picture Quality Contrast Ratio 4000:1 Response Time 8 ms Backlighting Technology Edge LED Connectivity
2 x HDMI 2.0 Audio, Video 1 x DVI-D Video 1 x 1/8″ / 3.5 mm Audio
Input Ports Output Ports 1 x 1/8″ / 3.5 mm Audio
2 x USB 2.0 Type-A
Ethernet Ports 1 Control RS-232C via 1/8″ / 3.5 mm Input/Output Wi-Fi Built-in Bluetooth Yes General TV Tuner No Display Orientation Landscape, Portrait HDCP Support Yes, Version 2.2 Surface Surface Treatment Anti-Glare Audio Built-In Speakers Yes, 2 x 10 W Speaker Configuration 2-Channel Hardware
Ethernet Ports 1 Control Operating System Tizen 4.0 CPU 1.7 GHz Cortex A72 Quad-Core Storage 8 GB RAM 2.5 GB LPDDR4 1500 MHz Convenience
Supported Video File Types Supported Audio File Types AC3 Supported Photo File Types JPEG, PNG Electrical
Power Consumption Standby 0.5 W
Power Consumption AC Input Power 100 to 240 VAC, 50 / 60 Hz Environmental
Power Consumption Operating Temperature 32 to 104 F / 0 to 40 C
Power Consumption Operating Humidity 10 to 80% Certifications
Power Consumption ENERGY STAR, as per Manufacturer Physical Wall Mounting 200 x 200 mm IP Rating IP5X IR Sensor Yes Bezel Thickness 9.2 mm (Right/Top/Left) Duty Cycle 16 Hours / 7 Days Dimensions 38.1 x 22.0 x 1.9″ / 967.5 x 557.7 x 48.3 mm Weight 10 lb / 4.5 kg Packaging Info Package Weight 28.5 lb
Power Consumption Box Dimensions (LxWxH) 42.75 x 26.75 x 6″
