Deliver a new, advanced level of learning for the future of education

• WM85B – Flip Pro 4K UHD Interactive Display for Education and Business
• • Drawing experience with 2,048 points of pressure with industry-best latency at just 26ms.
  • A real-world writing experience with pen and brush mode, quick tool and palette.
  • Versatile connectivity including USB-C, USB, HDMI, DP and OPS slot and easy wireless screen sharing.
  • Engaging learning experience with MimioConnect Blended Learning Platform and Video call applications.

Specification

Display
Screen Size:- 85″
Panel Technology :- VA
Resolution :- 3,840 x 2,160
Brightness :- 350 nits
Contrast Ratio (Typical) :- 4000:1(without glass)
Viewing Angle :- (H/V) 178/178
Response Time :- 8ms
Operation Hours :- 16/7
Pixel Pitch (HxV) :- 0.4875(H) mm x 0.4875(W) mm
Color Gamut :- 72%
Glass Haze :- 2%(without glass)
H-Scanning Frequency :- 30~81kHz
Maximum Pixel Frequency :- 594Mhz
V-Scanning Frequency :- 48~75Hz

Connectivity
HDMI In :- 2
DVI In :- 1
USB :- 4 (A type : Front 2, Rear 1, C Type : Front 1)
RS232 :- In Yes
RJ45 In :- Yes
WiFi :- Yes
Bluetooth® :- Yes
Version of HDMI :- 2
Version of HDCP :- 2.2
Audio Output Stereo :- Mini Jack
Verison of DP :- 1.2
Device :- Sharing SmartView+, Airplay

Power
Power Supply :- AC100-240V 50/60Hz
Power Consumption :- (On Mode) 528W(100-240V), 506W(220-240V), OPS(16V/4.5A) W
Power Consumption :- (Sleep Mode) 0.5W

Environmental Conditions
Operating Temperature :- 0℃~40℃
Operating Humidity :- 10 ~ 80%, non-condensing

Features
Touchscreen :- Yes
Learning platform :- MimioConnect Blended Learning platform
System On Chip :- Yes

Touch
Type :- IR
Dimensions Packaging (W x H x D) :-
2136 x 1318 x 260 mm
Bezel Width :- 20.4mm(T/LR), 44.7mm(B)
Set Dimension (WxHxD) :- 1945.8 x 1151.1 x 89 mm

Weight
Product Weight  :- 75.2 kg
Package Weight :- 91.6 kg
Service
Standard Warranty :- 5 Years

Accessories
Mount :- Yes(Model Name : WMN8200SF)

Mechanical Specification
VESA Mount :- 600 x 400 mm
Frame :- Material Metal (Aluminum)

SoC
OS Version Tizen :- 6.5
Flash Memory Size :- 32GB

Certification and Compliance
EMC
Class A FCC (USA) Part 15, Subpart B, KCC/EK (Korea) Tuner : KN32 / KN35, Tunerless : KN32 / KN35 CE (Europe) EN55032 : 2012 or 2015, EN55024:2010 or EN 55035:2017 VCCI (Japan) VCCI CISPR32:2016, CCC(China) GB/T9254-2008, GB17625.1-2012 BSMI (Taiwan) CNS13438 ( ITE EMI ) CNS14336-1 ( ITE Safety ) CNS15663 (RoHS) , C-Tick (Australia) AS/NZS CISPR32:2015, GOST(Russia/CIS) ROCT CISPR 24-2013 　 ROCT CISPR 22:2005

Safety
CB (Europe) : IEC60950-1/EN60950-1CCC (China) : GB4943.1-2011PSB (Singapore ) : PSB+IEC60950-1NOM (Mexico ) : NOM-001-SCFI-1993IRAM (Argentina ) : IRAM+IEC60950-1SASO (Saudi Arabia ) : SASO+IEC60950-1BIS(India) : IEC60950-1 / IS13252NOM(Mexico) : Tuner : NOM-001-SCFI-1993 Tunerless : NOM-019-SCFI-1998KC(Korea) : K 60950-1EAC(Russia) : EAC+IEC60950-1INMETRO(Brazil) : INMETRO+IEC60950-1BSMI(Taiwan) : BSMI+IEC60950-1RCM(Australia) : IEC60950-1/AS/NZS 60950-1UL(USA) : cUL60950

Cisco Certified :- Yes
