Display stunning 4K60 content using NEC’s proprietary high-performance video processing/scaling chip without the loss of critical details. HDR10 and BT.2020 signals from Ultra HD Blu-ray and 4K TV broadcasting are supported on all digital inputs.

Simplify your installations with HDBaseT, which is optimized for video applications and supporting uncompressed full HD digital video, audio, ethernet, power, and various control signals. With only a single cable (up to 328′) to run, infrastructure and labor costs are reduced, installations are significantly easier, and there is no cable clutter to manage. With uncompressed HD video support, images have never been more stunning. What’s more, control signals are contained in the same cable.

Integrated software applications such as AMX Beacon, Crestron Roomview, Extron XTP, and PJ Link allow for complete interactivity and control. Basic control of competitors product reduces the need for reprogramming of a control system.

ProAssist is software for controlling the projector and adjusting the projected image on the screen from a computer via a network. It allows necessary adjustments to be carried out easily when combining several projectors together to project a large screen in a classroom, meeting room, auditorium or other large space.

Enjoy installation flexibility with motorized optional bayonet-style lenses, providing quick and easy exchanges. Lens throw distances range from 2.5 to 68.5 ft. Customers utilizing previous generation NEC PA Series projectors can use their existing lenses. The following are all compatible models, both legacy and current.





Throw Ratio	Lens Type	Model Number
0.79:1	Short-throw lens	NP11FL
1.16-1.52:1	Standard-throw lens	NP12ZL
1.46-2.95:1	Standard-throw lens	NP13ZL
2.90-4.64:1	Long-throw zoom lens	NP14ZL
4.59-7.02:1	Long-throw zoom lens	NP15ZL
0.32:1	Ultra-short-throw lens	NP44ML-01LK
0.6-0.76:1	Short-throw zoom lens	NP50ZL
0.79-1.11:1	Short-throw zoom lens	NP40ZL
1.30-3.02:1	Standard-throw zoom lens	NP41ZL
2.99-5.93:1	Long-throw zoom lens	NP43ZL





• WUXGA native resolution
• Motorized zoom and focus
• Lens shift
• Cornerstone correction
• 3.5mm variable audio output
• Quick power on/off
• ECO Mode
• 360° roll-free installation
• Portrait mode
• Control over LAN or RS-232
• NaViSet Administrator 2
• Built-in wall color correction
• AutoSense
• Auto power off
